AeroCool KCAS-750G
750 W, 20+4 pin, ATX12V: 2.4, cooling system: 1 fan (120mm), backlight color: RGB
750 W, 20+4 pin, ATX12V: 2.4, cooling system: 1 fan (120mm), backlight color: RGB
General Characteristics |
|
Form-factor |
ATX |
Powers |
750 W |
Cooling System |
1 fan |
Fan diameter |
120 mm |
Version ATX12V |
2.4 |
EPS12V Support |
|
Certificate 80 PLUS |
gold |
Current on line +12V |
62.5 A |
Number of individual lines +12V |
1 |
Combined load at +12V |
750 W |
KPA |
90 % |
Power cable length 12V |
0.5 km |
Power cabling length |
0.5 km |
connectors |
|
Unplugged cables |
|
Type of connector for motherboard |
20+4 pin |
Number of connectors 4-pin CPU |
1 |
Number of connectors 4 + 4 pin CPU |
1 |
Number of connectors 8-pin CPU |
1 |
Number of connectors 6-pin PCI-E |
1 |
Number of connectors 6+2-pin PCI-E |
2 |
Number of connectors 8-pin PCI-E |
4 |
Number of connectors 4-pin IDE |
4 |
Number of connectors 15-pin SATA |
7 |
Number of connectors 4-pin Floppy |
1 |
Input voltage |
|
Minimums |
200 W |
Maximal |
240 W |
Supplementary Information |
|
Fan backlighting |
|
Colors of the power supply unit |
black |
Dimensions |
|
Width |
150 mm |
Heights |
86 mm |
Depth |
150 mm |
